This is the panel mount controller used in all our residential DX2W modules. You will need to specify in your order comments whether you have the first generation 36"x24"x14" coax heat exchanger module or the second generation 24"x24"x14" tube-in-shell heat exchanger module since they have different I/O configurations and software versions. If your system used a tank heater or has floor or panel cooling options or was customized in any way you will need to specify the name of the original customer so we can lookup the software revision used and burn it onto the new controller before shipping it to you. https://thermatlantic.com/dx2w....-panel-mount-control

We now stock competitively priced PEX-AL Oxygen Barrier (OB) tubing in 1/2" ID in 300 M (985') long rolls to be used with our XPS-AL panels. One roll should be sufficient for four 120 SF bundles of panels. Although PEX-B has become the most popular tubing in North America for radiant heating applications, this is largely due to its lower cost compared to the other two types available. https://thermatlantic.com/pex-....al-tubing-1-2-id-x-3

ThermAtlantic 40 USG Stainless Steel Indirect Tank with one 50' long 1" ID stainless steel coils with 1-1/4" FNPT ports, Mg Anode, 3/4" FNPT T&P & drain ports, 1-1/2" & 1" FNPT ports for optional heating elements or connections, 2 x 1/2" thermal wells, 2" Polyurethane foam insulation. This tank was specially designed to be used for heating domestic hot water using an external heat source. It can also be fitted with optional field-installed backup heat elements which can eliminate the need for a backup boiler in some installations. Made from 14 AWG high-quality Duplex stainless steel, these tanks are designed to last at least 10 years when used in potable water applications. The tank is rated for use up to 90°C / 194°F and up to 150 PSI and requires the purchase of a separate T&P valve suited for the application. https://thermatlantic.com/40-u....sg-stainless-steel-s

ThermAtlantic 120 USG Stainless Steel Indirect Tank with two 50' long 1" ID stainless steel coils with 1-1/4" FNPT ports, Mg Anode, 3/4" FNPT T&P & drain ports, 1-1/2" & 1" FNPT ports for optional heating elements or connections, 2 x 1/2" thermal wells, 2" Polyurethane foam insulation. This tank was specifically designed for heating domestic hot water using an external heat source. Follow the link to buy now. https://thermatlantic.com/120-....usg-stainless-steel-
